PIR Occupancy Sensor Wall Mount 2 Wire

Part Code PMWS2W

Key Features

  • Up to 2000W
  • Incandescent, halogen, fluorescent, LED and energy saving loads
  • Pre-wired
  • Spring clips for easy and quick installation
  • Detection angle - 110° @ 1.7m height
  • 10m radius @ 1.7m height detection distance
  • 1.7 wall mounting height
  • 30 - 200 lux adjustment
  • Auto / off slide switch control

Specification

Colour
White
Depth
40mm
Detection Angle
110°
Detection Range
10m
Dimensions
(H)85 mm x (W)85 mm x (D)40 mm
Guarantee
1 Year
Height
85mm
IP Rating
IP20
Logistics Partner
NONE
Lux Adjustment
Yes
Maximum Switching Load
Incandescent - 600w, Mains halogen - 400w, LV halogen - 200w, Fluorescent (uncompensated) - 150w, LED - 150w, Energy saving - 120w,
Mounting
Wall
Mounting Height
1.7m
Number Of Wire Connections
2
Packaging Types
Each
Remote Control
No
Similar Stock
No
Similar Stock Code
LTC-LSOS-2WIRE-WHI
Size
596mm x 596mm x 12mm
Timer Adjustment
10 sec - 40 min
Type
Wall Mounted Occupancy Sensor
Unspsc V13
39122236
Unspsc V18
39122236
Unspsc V22
39122236
Unspsc V24
39122236
Voltage Rating
230V
Weight
0.2009kg
Width
85mm
